AMD Ryzen Soft Router – 8 CPU Router

8 Core 16 Thread Router with 2.5bE

Topton AMD Ryzen 4×2.5G Soft Router, is a powerful router or mini server with up to 8 cores 16 threads and a low TDP of 15 Watts. It sells for $340 on aliexpress.us for the 6 core, no ram no storage up to $429 for 8 cores 16 threads with 4.5 GHz.

Subscribe to my free email newsletter and receive bonus content…

Models

Processors	Cores & Threads	Cache	Base Frequency	Max Turbo Frequency	TDP	Graphics
Ryzen 5 5600U	6 cores, 12 threads	16M	2.30 GHz	4.20 GHz	15W	AMD Radeon Graphics 7 Core 1800MHz
Ryzen 7 5800U	8 cores, 16 threads	16M	1.90 GHz	4.40 GHz	15W	AMD Radeon Graphics 8 Core 2000MHz
Ryzen 7 5825U	8 cores, 16 threads	16M	2.00 GHz	4.50 GHz	15W	AMD Radeon Graphics 8 Core 2000MHz

Specifications

4xIntel i226-V 2.5G UDE filter pure RJ45 LANs, 2xUSB3.1, 2xUSB2.0, 1xUSB Type-C, 1xTF card slot
2xDDR4 SODIMM non-ecc ram slot, support 3200MHz
Support five storage: 2xM.2 NVMe/PCIe3.0x4 2280 SSD(via M.2 2232 to 2280 PCB adapter board)+1xM.2 NVMe/PCIe3.0x4 SSD(an interface on the motherboard of CPU’s side)+1×2.5”SATA3.0 SSD/HDD(internal mounting)+1×2.5”SATA3.0 SSD/HDD(external from knock-out hole).
1xM.2 KEY-E 2232 slot, support WiFi connection, also support transfer to 1xM.2 NVMe/PCIe3.0x4 2280 SSD with PCB adapter board
Full-featured Type-C support data, display, reverse charging
TF card slot support storage and system disk boot
Support three display: 1xHDMI2.0, 1xDP1.4, 1xType-C, 3x4K@60Hz UHD video display
Support wide voltage 12-19V input
Support TPM2.0, ESXI, PVE, Watchdog, Auto power on, RTC, PXE boot, Wake-on-LAN etc
Full Aluminum Alloy high quality solid-built shell, excellent cooling performance, Exquisite production craft on outside design
Turbo silent fan with dual copper tube, durability for industrial grade field, work as long as 7×24 hours
